Clock Buffer Driver Distributor Chip 9DBL0641BKILFT
Description
2 to 8-Output 3.3V PCIe
Zero-Delay/Fanout Buffers
Features
The 9DBL02x2/9DBL04x2/ 9DBL06x1/9DBL08x1 buffers are
low-power, high-performance members of Renesas' full featured
PCIe family. The buffers support PCIe Gen1 through Gen5.
9DBL02x2/9DBL04x2/
9DBL06x1/9DBL08x1
Datasheet
▪ 2 to 8 Low-Power HCSL (LP-HCSL) outputs eliminate 4
resistors per output pair
▪ 9DBLxx4x devices provide integrated 100Ω terminations
▪ 9DBLxx5x devices provide integrated 85Ω terminations
PCIe Clocking Architectures
▪ Common Clocked (CC)
▪ Independent Reference (IR) with and without spread spectrum
(SRIS, SRNS)
Typical Applications
▪ PCIe Riser Cards
▪ nVME Storage
▪ Networking
▪ Accelerators
▪ Industrial Control/Embedded
Key Specifications
▪ Additive PCIe Gen5 CC jitter < 60fs RMS (fan-out mode)
▪ PCIe Gen5 CC jitter < 150fs RMS (High-BW ZDB Mode)
Packaging and transportation instructions
- According to the standard export packaging.
Customers can choose from cartons, wooden cases and wooden pallets
according to their own requirements.
Q&A
1. How to obtain the price?
We usually quote within 24 hours after receiving your inquiry
(except weekends and holidays). If you are in urgent need of a
price, please send us an email or contact us in any other way so
that we can provide you with a quotation.
2. What is your delivery time?
This depends on the quantity of the order and the season in which
you place the order. Usually, we can ship the goods within 7 to 15
days (for small batches), and for large batches, it takes about 30
days.
3. What are your payment terms?
Factory price, 30% deposit, 70%T/T payment before shipment.
4. What is the mode of transportation?
It can be transported by sea, air or express delivery (EMS, UPS,
DHL, TNT, FEDEX, etc.). Please confirm with us before placing an
order.
5. How do you help our business establish a long-term and good
relationship?
We maintain good quality and competitive prices to ensure that our
customers benefit.
2. We respect every customer as our friend. We do business with
them sincerely and make friends with them, no matter where they
come from.
